Documented Sensor Model
AESD00100SPO
Miniature Diffuse Photoelectric Sensor
Compact flat-body diffuse sensor for short-range object detection in tight machine spaces.
Representative imageOverview
AESD00100SPO is a compact diffuse-reflection sensor for machinery where mounting depth and available space are limited. Its flat body and short sensing range make it a practical starting point for controlled presence-detection tasks.
Final selection should be checked against the target colour, reflectivity, mounting position, and controller input.
Verified Record
Technical specifications.
Confirm the exact supplied item and current documentation before final specification or installation.
- Sensor principle
- Diffuse reflection photoelectric detection
- Body style
- Flat compact body
- Housing and lens
- PC and PBT housing; PC lens
- Sensing range
- 100 mm rated sensing distance
- Reference target
- 50 x 50 mm white card
- Light source
- Visible red light, 640 nm
- Output type
- PNP
- Output logic
- NO
- Supply voltage
- 10 to 30 VDC
- Load current
- 50 mA maximum
- Response time
- Less than 1 ms
- Protection
- Short-circuit, overload, and reverse-polarity protection
- Protection degree
- IP65
- Operating temperature
- -20 to +55 degrees C
- Dimensions
- 19.6 x 14 x 4.2 mm
- Connection
- 2 m cable
Typical Applications
Where this model fits.
- Small conveyors
- Compact fixtures
- Object presence detection
- Packaging machinery
- Space-limited panels
Selection Notes
What to verify.
- Use where an M18 barrel sensor will not physically fit.
- Best suited to short-range detection in controlled industrial environments.
- Confirm target colour and reflectivity before selection.
Before Quotation
Questions to answer.
- Will the target pass within 100 mm of the sensing face?
- Is the PLC or input card PNP compatible?
- Is the mounting area exposed to washdown or dust?
